2.0 Product overview
2.1 General product informaon
The DR4088RB-xx is a feedback module that can be connected to the control panel via the R-Bus®.
The DR4088RB-xx has 16 feedback inputs.
The DR4088RB-xx is available as CS version (current sensor 2-wire track) and OPTO version (connecon of reed contacts, 3-wire track signal to track ground).
2.2 Technical specicaons
The connecon terminals of the 16 feedback units are designed for a cross-secon of 0.5mm², the two terminals for "C" are designed for a cross-secon of
0.75mm².
Number of in-
puts
Suitable
for
Minimum load for
safe reporng
Max. load per
contact Load per
contact
Max. load per
contact Load ca-
pacity
per contact for
max. 100 ms
Peak load for 8 feed-
backs at "C" total
Peak load for 8
feedbacks at "C"
total.
DR4088CS 2 x 8 2 conductors 2 mA 2 A 5 A 6 A an „C“ 6 A an „C“
DR4088OPTO 2 x 8 3 conductors
when using the
DR50xx
- - - -
