4
Surface Mount Installation
For door thickness measuring between .01" - .91" (0.2 mm - 23 mm)
1 - Front Unit
Key Managed Code Managed
Deadbolt Deadlatch
1 - Rear Unit
2 - Phillips Head Screws
2 - Split Lock Washers
Required Components
*Not included
1* - Phillips Head Screwdriver (#2)
