Digilock NEXTLOCK CUE Series - Installation Steps; Unit Mounting and Testing

5
REAR VIEW FRONT VIEW
1
REAR VIEW FRONT VIEW
2
With the rear unit behind the door, extend the cable through the door’s mounting hole�
Installation
For illustration, a bolt rear unit is used.
REAR VIEW FRONT VIEW
3
Attach the cable to the front unit� A triple beep indicates successful connection�
Hold the front and rear units against the door and secure with the mounting screws�
