Digisol DG-GR1321 User Manual

1:1 Product Description
Overview
Figure 1
Thank you for choosing DG-GR1321 ONU. The terminal devices are
designed for fulfilling FTTH and triple play service demand of fixed network
operators or cable operators. The device is based on mature GPON and
Gigabit EPON technology, which has high ratio of performance to price, and
the technology of 802.11n WiFi (2T2R), Layer 2/3, and high quality VoIP as
well. They are highly reliable and easy to maintain, with guaranteed QoS for
different service. And it is fully compliant with GPON and EPON technical
regulations such as ITU-T G.984.x & IEEE802.3ah. DG-GR1321 is a dual
mode ONU which can detect and exchange PON mode automatically.
1:2 Application Chart
Figure 2

Digisol DG-GR1321 Specifications

General

Model	DG-GR1321
Category	Wireless Router
Frequency Band	2.4 GHz
Antenna	2 x 5dBi External Antennas
WAN Port	1 x 10/100Mbps
LAN Ports	4 x 10/100Mbps
WAN Connection Type	Dynamic IP, Static IP, PPPoE, PPTP, L2TP
QoS	Yes
Wi-Fi Standards	IEEE 802.11n
Wireless Speed	300 Mbps
Security	WPA/WPA2, WEP
Firewall	SPI Firewall
