Digisol DG-GR1321 User Manual

1:3 Technical Parameters
Technical item DG-GR1321
PON interface 1 GPON/EPON connector, SC single-mode/single-fiber,
GPON: uplink 1.25Gbps, downlink 2.5Gbps;
EPON: symmetric 1.25Gbps
Wavelength Tx:1310nm, Rx:1490nm
Optical interface SC connector
LAN interface 1* 10/100/1000Mbps and 1*10/100Mbps auto adaptive
Ethernet interfaces (RJ45). 1* POTS (RJ11).
Wireless Compliant with IEEE802.11b/g/n, 300Mbps,
2T2R two external antennas.
LED 8 indicators for status of POWER, PON, LOS, WAN,
WIFI, POTS, LAN, Pair.
Operating condition Temperature: -5°C ~ +55°C
Humidity: 10% 90% (non-condensing) ~
Storing condition Temperature: -30 60°C ~ °C
Humidity: 10% 90% (non-condensing) ~
Power supply DC 12V/1A
Power consumption ≤6W
Dimension 185mm×120mm×34mm (L×W×H)
Net weight 0.24Kg
1:4 Package Content
Contents Quantity
ONU 1 PCS
Power Adapter 1 PCS
QIG 1 PCS

Digisol DG-GR1321 Specifications

General

Model	DG-GR1321
Category	Wireless Router
Frequency Band	2.4 GHz
Antenna	2 x 5dBi External Antennas
WAN Port	1 x 10/100Mbps
LAN Ports	4 x 10/100Mbps
WAN Connection Type	Dynamic IP, Static IP, PPPoE, PPTP, L2TP
QoS	Yes
Wi-Fi Standards	IEEE 802.11n
Wireless Speed	300 Mbps
Security	WPA/WPA2, WEP
Firewall	SPI Firewall
