1:5 Panel Description
Figure 3
Name Function
PON Connect GPON or EPON port with internet by SC type,
single mode optical fiber cable.
FXS 1 Connect the telephone with FXS port by telephone wire.
LAN1 / LAN2 Connect PC to device Ethernet port by RJ-45 cable.
Pair (Wireless Pair) Press down Wi-Fi pair button for WPS function.
WiFi Press down Wi-Fi button to enable/disable Wi-Fi
function.
RST Press down reset button to make the device restart and
recover with factory default settings.
PWR To connect power adapter.
