WIRING TABLE
PIN REF.
SIGNAL DESCRIPTION WIRE SECTION
mmq
CONNECT TO:
M3-6
GROUND CONNECTION
3x1 EARTH
M3-5
MAINS INPUT (NEUTRAL)
3x1 230 Vac
M3-4
MAINS INPUT (PHASE)
3x1 230 Vac
M3-3
GROUND and SHIELD CONNECTION 3x1
shielded
VIBRATOR (if provided)
M3-2
OUTPU SUPPLY FOR VIBRATOR
3x1
shielded
VIBRATOR COIL
M3-1
OUTPU SUPPLY FOR VIBRATOR
3x1
shielded
VIBRATOR COIL
M2-9
CURRENT REFERENCE (0-20mA) 0,35
M2-8
VOLTAGE REFERENCE (0-5V) 0,35 VOLTAGE REF.
M2-7
POTENTIOMETER CURSOR 0,35 CURSOR
M2-6
POTENTIOMETER MINIMUM 0,35 COUNTERCLOCKWISE
M2-5
POTENTIOMETER MAXIMUM 0,35 CLOCKWISE
M2-4
0V INSULATED FOR REMOTE
COMMANDS
0,35
M2-3
REMOTE START-STOP COMMAND 0,35
M2-2
OUTPUT POWER SUPPLY OK 0,35
M2-1
+18V INSULATED FOR REMOTE
COMMANDS
0,35
Note: The guts of the vibrator must be grounded with a appropriate wire.
Before supplyng the device verify that there are not ground dispersions on
wires connecting the power supply to the vibrator; The power supply will be
damaged if one of the two output wires is grounded.
