Digital Projection E-Vision Laser 7500, 8500 & 10K Series
Reference Guide
APPENDIX D: GLOSSARY OF TERMS
Rev D August 2017
Synchronization
A timing signal used to coordinate an action.
Test pattern
A still image specially prepared for testing a projection system. It may contain various combinations of colors, lines and geometric shapes.
TheaterScope
An aspect ratio used in conjunction with a special anamorphic lens to display 2.35:1 images packed into a 16:9 frame.
Throw distance
The distance between the screen and the projector.
Throw ratio
The ratio of the throw distance to the screen width.
TRC (Throw ratio correction)
A special number used in calculating throw distances and throw ratios when the image does not ll the width of the DMD™.
TRC is the ratio of the DMD™ aspect ratio to the image source aspect ratio:
DMD™ aspect ratio
Source aspect ratio
TRC =
TRC is only used in calculations if it is greater than 1.
UXGA
A display resolution of 1600 x 1200 pixels with a 4:3 screen aspect ratio. (Stands for Ultra Extended Graphics Array.)
Notes

Digital Projection E-Vision Laser 7500 Series Specifications

General

Resolution	1920 x 1200 (WUXGA)
Light Source Life	20, 000 hours
Input Lag	16ms
3D Support	Yes
HDBaseT	Yes
Brightness	7500 Lumens
Light Source	Laser
Weight	19 kg (without lens)
