IPEX5000 Series Quick Install Guide
16
Video Wall
In addion to matrix conguraons, mulple IPEX5002 devices can be congured to make a video wall up to
16x16 in size. This funconality is also managed through the Digitalinx IP Control soware for Windows and iPad
or through a third party controller.
Please see the Digitalinx IP Deployment Guide for conguring this funconality.
IPEXCB
IPEX5001
IPEX5002
(x20)
IPEX5002
IPEX5002
IPEX5002
IPEX5001
IPEX5001
IPEX5001
Third Party Controller
iPad with
IPLinx Control
Wireless Access
Point
Windows PC with
IPLinx Control
IR Remote
IR Remote
Switch
Apple TV
Set top box
4K media player
Workstation
Video Ethernet RS232 / USB / IR Analog Audio
Amplier
4x5 Video Wall
Display
Display
KVM
Audio/Video Input
System Control
Audio/Video Output
IN
ANALOG AUDIO
OUT
IN
ANALOG AUDIO
OUT
IN
ANALOG AUDIO
OUT
IN
ANALOG AUDIO
OUT
