IPEX5000 Series Quick Install Guide
6
The Digitalinx IP IPEX5002 receives HDMI video and audio over a 1 gigabit network infrastructure using JPEG2000
encoding from the IPEX5001 and IPEX5001-WP-W encoder. The IPEX5002 outputs video signals navely from
source or can be scaled to 1080p or 4K at 24/30Hz 4:4:4 with HDR10, HDCP 2.2 and mulchannel audio support.
An analog audio output port de-embeds stereo 2 channel audio from the HDMI content while sll passing stereo 2
channel audio to the HDMI output. Depending on the needs of the installaon, mulple IPEX5002 devices can be
congured to make a video wall up to a 16x16 conguraon.
The IPEX5002 supports PoE power and can be powered remotely via PoE network switch eliminang the need for a
nearby power outlet. The RS232 port relays commands from the IPEXCB controller and operates in a pass through
mode to control a third party device such as a TV display or HDMI switcher. The USB client port connecons is for
connecng USB client devices such as an interacve white board or HID devices that is USB 2.0 Full Speed compliant
up to 12Mbps that can communicate with the host device connected to an encoder. USB roung follows the video
route by default however USB communicaon can be free routed via API. The IPEX5001 features bi-direconal IR
support which follows the video route or can be routed freely via API command.
The IPEX5002 requires a single IPEX5001 for a point to point installaon. When mulple IPEX50012
and/or IPEX5001 devices are in a system, an IPEXCB control box will be required.
IPEX5002 Decoder
