DigitaLinx IPEX5000 Series - IPEX5001 Encoder; Product Overview

IPEX5000 Series Quick Install Guide
5
The Digitalinx IP IPEX5001 transmits HDMI video and audio over a 1 gigabit network infrastructure using JPEG2000
encoding with a variable data rate at an average of 250 Mbps with peak values up to 850Mbps. The IPEX5001
supports video signals up to 4K at 60 Hz 4:2:0 / 8 bit color with HDR10, HDCP 2.2 and mulchannel audio support.
An analog audio input port embeds analog audio with the video content, such as a DVI video source. An analog
audio output port de-embeds stereo 2 channel audio from the HDMI content, while sll passing stereo 2 channel
audio to the HDMI output.
The IPEX5001 supports PoE power and can be powered remotely via PoE network switch eliminang the need
for a nearby power outlet. The RS232 port relays commands from the IPEXCB controller and operates in a pass
through mode to control a third party device such as a TV display or HDMI switcher. The USB host port connecon
is for connecng USB host devices such as a computer that is USB 2.0 Full Speed compliant up to 12Mbps that
can communicate with client side devices connected to a decoder. USB roung follows the video route by default
however USB communicaon can be free routed via API. The IPEX5001 features bi-direconal IR support which
follows the video route or can be routed freely via API command.
The IPEX5001 requires a single IPEX5002 for a point to point installaon. When mulple IPEX5001
and/or IPEX5002 devices are in a system, an IPEXCB interface will be required.
Product Overview
IPEX5001 Encoder
The Digitalinx IP IPEX5001-WP-W transmits HDMI or VGA video and audio over a 1 gigabit network infrastructure
using JPEG2000 encoding with a variable data rate at an average of 250 Mbps with peak values up to 850Mbps. The
IPEX5001-WP-W supports video signals up to 4K at 60 Hz 4:2:0 / 8 bit color with HDR10, HDCP 2.2 and mulchannel
audio support. An analog audio input port embeds analog audio with the video content, such as a DVI video source.
An analog audio output port de-embeds stereo 2 channel audio from the HDMI content, while sll passing stereo
2 channel audio to the HDMI output. The HDMI and VGA inputs on the IPEX5001-WP-W are auto switching and
follow the last in / rst out method and must be physically connected / disconnected to engage the auto switch.
The IPEX5001-WP-W supports PoE power and can be powered remotely via PoE network switch eliminang the
need for a nearby power outlet. The RS232 port relays commands from the IPEXCB controller and operates in a pass
through mode to control a third party device such as a TV display or HDMI switcher. The USB host port connecon
is for connecng USB host devices such as a computer that is USB 2.0 Full Speed compliant up to 12Mbps that can
communicate with client side devices connected to the decoder. USB roung follows the video route by default
however USB communicaon can be free routed via API. The IPEX5001-WP-W features a built in IR receiver built in
on the plate, IR follows the video route or can be routed freely via API command.
IPEX5001-WP-W Encoder
