Page #36 background imageLoading...
Page #36 background image

TheinformationcontainedherearepropertyofDIGITAXAutomotiveElectronicsItaly,andextremelyconfidential.Anydisclosure,copying,distributiontothird
partyisstrictlyprohibited.

36
Nr. Functions Value
VARIOUS FUNCTIONS
192 Disable auto-shutoff if car-lights are ON? - In Stopped with auto-shut-off disabled the taxi-meter will allways remain ON. In case auto-shut-off is enabled the taxi-meter
will switch OFF automatically after the amount of time programmed in Q.284. The allowed answer is either: 0 (No: enabled) or: 1 (Yes: disabled).
No / Yes
193 Enable the light-test? When this option is enabled then in case of an error the message 'ERROR' 'LIGHT' will appear on the display. The light-test is done on the moment of
passing from Stopped to Hired. The lights tested are: TAXI, light 1 to light 4. The allowed answer is either: 0 (No: disabled) or: 1 (Yes: enabled).
No / Yes
194 Block the taxi-meter on light-error? - At the end of the current fare should the taxi-meter be blocked in case of a light-error?
The allowed answer is either: 0 (No: don't block) or: 1 (Yes: block).
No / Yes
195 Enable the display-segment-test? - When this option is enabled then in case of an error the message 'ERROR' 'DISPL' will appear on the display. The display-segment-
test is done on the moment of passing from Stopped to Hired. The lights tested are: TAXI and light 1 to light 4.
The allowed answer is either: 0 (No: disabled) or: 1 (Yes: enabled).
No / Yes
196 Block taxi-meter on disp.-segment-error? - At the end of the current fare should the taxi-meter be blocked in case of a display-segment-error?
The allowed answer is either: 0 (No: don't block) or: 1 (Yes: block).
No / Yes
197 Disable the display-dim function? - The possibility to dim the display should be disabled? General: the allowed answer is either: 0 (No: enable dimming) or: 1
(Yes: disable dimming). The intensity itself can be programmed with Q.198.
No / Yes
198 Intensity displ.-dim function is 50% or 75%? - The intensity of the display can be programmed to have one of two values: 50% or 75%.
The allowed answer is either: 0 (No: 50%) or: 1 (Yes: 75%). The display-dim function can be enabled by programming Q.197.
0=50%
1=75%
199 Fixed Cross-speed: the calculation of the cost of a fare is either based on time or based on distance.
Below a certain velocity it is convenient to calculate the cost based on time (and not on distance). Above that velocity however it is convenient to calculate the cost based on
distance (and not on time). This velocity is the so called cross-speed. At this velocity the calculated cost is the same for both time and distance. The velocity is given in Km/h
with an accuracy of 1 Km/h. The allowed value goes from 0 (min) to 255 (max).
A fixed cross-speed can be obtained by programming a value between 1 and 255 (Km/h). The value 0 is a special case (default). If 0 is programmed then the cross-speed is
calculated automatically based on Q.2/3/4 and Q.5/6/7.
0 - 255 km/h
200 Alarm-velocity speedometer: this is the velocity above which an acoustical alarm-signal is produced.
If the (over-) velocity is maintained for at least 5 sec. Then it gets registered in the statistics. The registration is maintained for the last 40 events. So, at event n. 41 event n. 1
gets lost. The alarm-velocity is given in Km/h with an accuracy of 1 Km/h. The allowed value goes from 0 (min) to 255 (max). The value 0 is a special case (default). If 0 is
programmed then the alarm speedometer is disabled.
0 - 255 km/h
201 Speedometer velocity-step: this is the step-amount (of velocity) with which the threshold of the speedometer gets decremented or incremented every time key K3 (dec.) or
key K4 (inc.) is pressed. The velocity-step is given in Km/h with an accuracy of 1 Km/h.
The allowed value goes from 0 (min) to 255 (max).
0-255
202 Enable manual setup of speedometer? - Should the possibility to setup the speedometer manually be enabled?
The allowed answer is either: 0 (No: disabled) or: 1 (Yes: enabled).
No / Yes
203 Show real-time speed on display? - Should the real-time speed of the car be shown on the secondary display? No / Yes
204 Show distance on display? - Should the (real-time) distance of the car be shown on the secondary display? No / Yes
205 Enable the Euro Conversion? No / Yes
206 Must the trip total amount be printed in Euro as well? No / Yes
207 During sums, extras insertion is not allowed? No / Yes
208 During sums, locks K4 (to avoid summing time to be extended) No / Yes
209 Disable the sum separation with K4? No / Yes
210 Starting-hour of dim-function: this is the moment (whole or half hour) starting from which the display will be dimmed (according to Q.197 and Q.198). The time is given in
whole hours with an accuracy of 1 hour. The allowed value goes from 0 (min) to 23 (max). It is also possible to specify half hours. In order to do this add 100 to the
programmed value. For example, to program the hour 22:30 use the value 122.
No / Yes
211 Ending-hour of dim-function: this is the moment (whole or half hour) starting from which the display will have normal intensity (according to Q.197 and Q.198). The time is
given in whole hours with an accuracy of 1 hour. The allowed value goes from 0 (min) to 23 (max).
It is also possible to specify half hours. In order to do this add 100 to the programmed value.
For example, to program the hour 22:30 use the value 122.
No / Yes
TAXI -LIGHT
212 Enable taxi-light ON in day-time? - Should it be possible for the taxi-light to be ON during the day-time?
The allowed answer is either: 0 (No: disabled) or: 1 (Yes: enabled).
No / Yes
213 The taxi-light must flash? - If Yes the taxi-light will flash. The allowed answer is either: 0 (No: no flash) or: 1 (Yes: flash). No / Yes
214 The taxi-light must go ON in overspeed? - If Yes then the taxi-light will go ON in case the actual velocity is higher than the velocity programmed in Q.200. The allowed
answer is either: 0 (No: OFF) or: 1 (Yes: ON).
No / Yes
215 Taxi-light must go on overspeed? No / Yes
from Q 216 / available for any possible software extension / to Q 218
219 Taxi-light ON in this tariff-block? - With Yes the taxi-light will go ON in the corrisponding tariff-block.
The allowed answer is either: 0 (No: OFF) or: 1 (Yes: ON).
No / Yes
