Page 9
MIDI Functions
The Whammy features a MIDI input for receiving incoming MIDI data. MIDI messages can select
a Whammy effect and set whether the effect is in an active or bypassed state. MIDI CC messages
can then be used to control the Whammy Expression Pedal position.
MIDI Channel
The Whammy can receive MIDI messages on any, or all MIDI channels. The following steps outline
the procedure for accessing or changing the MIDI channel.
1. Disconnect the power from the Whammy pedal.
2. Press and hold the Effect On/Off Footswitch while reconnecting the power. One of the
Effect LEDs will begin to flash indicating the currently selected MIDI channel.
3. Using the reference chart below, rotate the Selector Knob to select the desired MIDI
channel.
4. Press the Effect On/Off Footswitch again to exit the MIDI set up menu.
