© 2020 Digitrax, Inc. www.digitrax.com
7
7
The Loco Info Area is where the current or display focus locomotive
information for the active throttle knob is shown. Changing a knob speed,
direction or the key may change the throttle knob focus side. The
focus loco’s speed is then listed as “sp XX %”. At left is a loco icon with
the current direction indication. Showing forward as “F” and an arrow, or
reverse, shown with or an “R” and arrow. If a focus loco is currently
selected this loco icon will be green with ashing smoke above the smoke-
stack. If no loco is selected the icon will be gray with no smoke. The cur-
rently active address is shown in the large numbers in the center. If a loco
is selected the numbers will be solid black, if no loco is selected the num-
bers will be gray. The focus Loco Info area will show additional informa-
tion during locomotive selection, see section 4.1 for more information on
selecting locomotives.
1. The Status Bar is active for Home screen and will show the status of your
system. There are multiple indicators that appear in the Status Bar. The
“Ln” indicator is solid black when LocoNet is connected OK. The “Trk”
indicator is green when system track power is turned on. In IR or Duplex
mode connection information is shown.
2. The Switch/Fn Info + Area is where turnout or switch information is dis-
played in switch mode. Switch mode is covered in more detail in section
6.0. This area of the screen is also where the complete 29 function state is
displayed when the “Info +” soft key is pressed. Active/ON function num-
bers are blue and inactive/OFF functions are grayed out. For more info on
controlling and managing functions see section 5.0.
3. The Function Bar is where ten active locomotive decoder functions are
shown. The compact function information shown in this bar correlates to
the “Fn+” soft key, pressing the “Fn+” soft key will cycle through control
of higher functions and display them in the Function Bar. For more infor-
mation on using functions see section 5.0.
4. The Second Throttle Area shows information related to the alternate
non-focus throttle knob that is not currently the function-number display
and information focus.
5. Scrolling Help text line. Shows status and prompts user actions.
6. A/B/C soft key Bar. Indicates the adjacent soft key actions.
2.1.2 Screen IDLE Power saver
To save power and be ecologically responsive, the DT602 will enter a dark dis-
play screen IDLE after a user congurable no-activity timeout. When in a
power saving IDLE mode the key will ash green about every 3 seconds.
To exit IDLE mode press the or key to restore the color LCD display.
A short press of the key is a consistent way to return to the HOME screen
from any menu. Note: holding the the key for more than about 1 second
will perform Emergency Stop. See section 8.
