Digitus DS-12860 Quick Installation Guide

19
Product specification
HDMI KVM Version
Model Number
DS-12860
DS-12883
Computer connections
2
4
Port selection
Front panel buttons/Hotkey
Connector
Control
port
monitor
2 x HDMI Type A female
keyboard
1 x USB Type A female
mouse
1 x USB Type A female
speaker
1 x Mini stereo jack
female (green)
microphone
1 x Mini stereo jack
female (pink)
Computer
port
monitor
4 x HDMI
Type A female
8 x HDMI
Type A female
keyboard
and mouse
2 x USB
Type B female
4 x USB
Type B female
speaker &
microphone
2 x mini stereo
jack female
4 x mini stereo
jack female
Power ( Optional )
1 x DC 9V 300mA
Power Connector size
5.5x2.1mm
Toggle switch
KVM switch button
2 x button
4 x button
LED’s
Online
2 x red
4 x red
Selected
2 x green
4 x green
Analog mode
Keyboard and mouse
2x USB
Maximum resolution video
4K@30HZ(3840x2160 @30Hz)
Default Hotkey
[CTL] [CTL]
Operating
environment
Operating temperature
0-50 °C
Storage temperature
-20-60 °C
Humidity
0-80% RH , no condensation
Housing
House
Metal , Black
Size (mm)
132x92x66
202x110x66
Weight (g)
575g
920g

Digitus DS-12860 Specifications

General

DC-in jack	Yes
HDMI version	1.4b
Console ports	USB A
USB connector type	USB Type-A, USB Type-B
HDMI ports quantity	6
Number of computers controlled	2
Video bandwidth	30 Hz
Maximum resolution	3840 x 2160 pixels
Cables included	HDMI, KVM
Product color	Black
Rack mounting	No
LED indicators	Status
Housing material	Metal
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 80 °C
Operating relative humidity (H-H)	0 - 80 %
Country of origin	China
Harmonized System (HS) code	85176200

Weight and Dimensions

Depth	92 mm
Width	132 mm
Height	66 mm
Weight	575 g
