Digitus DS-55204 Quick Installation Guide

6
Accessory
5V1A power adapter x 2
IR transmitter x 1
IR receiver x 1
User manual x 1
5. Penal Description
Transmitter unit (TX)
①
Reset button
Press for restarting the unit
②
RJ45 signal output
Output encoded HDMI signal
③
Power indicator
LED indicator turn on when power on
④
DC5V input
Connect with the power supply
⑤
HDMI signal input
Connect with the source device
⑥
IR signal output
Connect with IR blaster extension cable
Receiver unit (RX)

Digitus DS-55204 Specifications

General

Brand	Digitus
Model	DS-55204
Category	Extender
Language	English
