Digium, Inc. Page 61
Appendix B
Specifications
This appendix provides specifications, required environmental
conditions, and maximum power consumption for the Gateway
Series appliances.
Physical (All Units).
Size: 8.6” × 9.0” × 1.72” (21.84 x 22.86 x 4.37 cm)
Weight: 2 lbs 12 oz (1,247.38 gm)
Interfaces.
Local Loop Access: E1, T1, PRI; RJ45 (A.K.A RJ48)
USB: Standard Type A Receptacle
Ethernet Access: 10/100/1000base-T; RJ45
Power: Standard 3-pin IEC320-C13
Environment.
Temperature: 0 to 50° C (32 to 122° F) operation
-20 to 70° C (4 to 158° F) storage
Humidity: 0 to 90% non-condensing
Power Requirements.
Voltage: 100-240VAC, 50/60Hz
Current: 0.5A maximum, 67mA@120V or 33mA@240V typical
Power: 10W maximum, 7.5W typical
