Digium, Inc. Page 64
Appendix B
Specifications
This appendix provides specifications, required environmental
conditions, and maximum power consumption for the TE400 Series
cards.
Physical (All Cards).
Size: 5” × 3.75” × 0.63” (12.7 x 9.53 x 1.6 cm)
PCB size, does not include the PCI bracket
Weight: 3.5 oz (100gm) - Without Echo Cancellation Module
Interfaces.
Local Loop Access: E1, T1, J1, PRI; RJ45
(TE405P/407P/410P/412P) - PCI Bus: 3.3V or 5V bus slot, half-
length slot minimum size, 33MHz minimum bus speed, compliant
with PCI 2.2 or greater.
(TE420) - PCI-E X1, compliant with PCI-E X1 1.0 or greater.
Environment.
Temperature: 0 to 50° C (32 to 122° F) operation
-20 to 65° C (4 to 149° F) storage
Humidity: 10 to 90% non-condensing
