Advanced Force Gauge User’s Manual
16
ALARM sub-menu 3 The display shows AUDIBLE, LED and BOTH with the
arrow cursor indicating which feature is selected. This
menu selects how the PASS/FAIL status of a value
will be indicated.
AUDIBLE Only the audible alarm will be activated
when the value is a PASS/FAIL
LED The green and red LED’s will indicate the
PASS /FAIL status.
BOTH Both the LED and the audible alarm will
be activated above.
Use UP and DOWN to move the cursor and press
ENTER to select the desired feature.
The display shows OUT BAND and IN BAND. This
menu selects which values are to be considered.
OUT BAND Any value falling outside the set limits
LIMIT 1 and LIMIT 2
IN BAND Any value falling between the set limits
LIMIT 1 and LIMIT 2
Use UP and DOWN to move the cursor and press
ENTER to select the desired feature.
The display shows PASS and FAIL. This menu sets
the OUT BAND and IN BAND mode.
PASS Values, which fall either OUT BAND (or IN
BAND, if selected), are a PASS
FAIL Values, which fall either OUT BAND (or IN
BAND, if selected), are a FAIL and will
cause an audible beep.
Use UP and DOWN to move the cursor and press
ENTER to select the desired feature.
Display is showing sub-menu 1 again (= ALARM ON
and SET). Press ESC to return to main menu and
again to return to main display. The main display will
now show an alarm ‘bell’ symbol indicating the alarm
is turned on. See Figure 8.
ALARM sub-menu 4
ALARM sub-menu 5
