10 www.dimplex.com
WARNING: Disconnect power before attempting any
maintenance to reduce the risk of electric shock or damage
to persons.
Gently place stove on it’s back on a at surface.1.
Remove the heater cover retaining screws located on 2.
the bottom of the stove and lower heater/light assembly
onto the oor.
Remove the reector rod and motor assembly by 3.
removing the screws on the front and rear of the heater
cover.
Disconnect the heater wiring connections from the 4.
heater noting their original locations.
Remove the 4 heater mounting screws and remove the 5.
heater from the unit.
Reassemble in the reverse order as above.6.
