Dimplex DXIONCF - Technical Specification; Product Specifications; Operating Instructions; Initial Setup and Controls

Technical Specication
DXIONCF Symbol Value Unit
Maximum Fan Flow Rate F 22.45 m³/min
Fan Power Input P 36.52 W
Service Value SV 0.67 (m³/min)/W
Standby Power Consumption PSB 0.584 W
Fan Sound Power Level LWA 59 dB(A)
Maximum Air Velocity c 2.646 m/s
Rated Voltage V 220 - 240 V
Rated Frequency Hz 50 Hz
Measurement Standard for Service
Value
IEC 60879:1986
Operating Instructions
This TOWER FAN can be operated using the manual controls located on the top of the
TOWER FAN (as shown in Fig. 3 below) or by using the remote control (shown in Fig.
2 previously) supplied with the product.
Place the fan on a stable at surface. Plug the cord set into a 220-240V~A.C.
electrical outlet. When the fan is plugged in the current room temperature will be
displayed on the display panel.
(Figure 3) (Figure 4)
