Dimplex EF830 - Display Information

11
EF830
In more detail . . .
Display
1 2 43 65 7
111098
1 Cursor 2 Day of the week
3 Timer icon 4 Temperature/timer number
5 Timer on 6 Timer off
7 Flame dim level 8 Heating level
- low heating level
- high heating level
9 Automatic heating mode 10 Time/temperature display
11 Standby mode icon
Product function
