6
Quick Reference Guide
Figure 1
1. The electrical information
regarding your electric replace
can be found on the rating label
located on the top of the unit.
2. If you have any technical
questions or concerns
regarding the operation of your
electric replace, or require
service contact the relavent
customer service as listed on
your warrenty card.
3. For dimensions of your
replace, refer to Figure 1.
Model No: XLF50-EU, XLF60-EU, XLF74-EU, XLF100-EU
Heat Output 230V 240V
Nominal Heat Output P
Nom
1.6 - 1.6 kW
Minimum Heat Output P
min
- - - kW
Maximum Continous Heat Output P
max,c
1.6 - 1.6 kW
Auxiliary Electricity Consumption
In Standby mode el
SB
0.47 - 0.49 W
Technical Information
with electronic room temperature control
