Maintenance
This product is fi tted with a replaceable battery in the controls.
To replace the battery, follow the steps below, shown in Fig. 6:
1. Unhinge the heater from the wall using the clips shown in Fig. 3 and locate
the battery module.
2. Slide the catch (1) and pull module from the controls (2).
3. Remove the coin cell battery and replace.
4. Slide module back in place, ensuring clip is engaged.
Fig. 6
IMPORTANT:
Before replacing the battery ensure the heater is isolated from the electricity supply.
NOTE:
Battery should be disposed of in an appropriate manner
4
Battery
positive
side up
3

Dimplex Q-Rad Series Specifications

General

Type	Electric Radiator
Thermostat	Yes
Installation	Wall-mounted
Finish	White
Frost Protection	Yes
Energy Saving Features	Adaptive start, Open window detection
Safety Features	Overheat protection
Dimensions	Varies by model
Weight	Varies by model
Warranty	2 years
Programming	7-day programmable timer
Mounting	Wall Mounted
Model	Q-Rad Series
Power Output	500W, 750W, 1000W, 1500W, 2000W
Voltage	230V
Energy Efficiency	High
