7
The heater is designed for wall mounting using the wall bracket supplied. It should only be
operated when in the upright position as shown - see Fig. 1 and Fig. 2. All models are splash
proof to IP24 standard and may be used in bathrooms, however not in the immediate vicinity
of baths, showers, water connections, wash basins or swimming pools. Before connecting the
heater check that the supply voltage is the same as that stated on the heater.
IMPORTANT – The wall bracket supplied with the appliance must be used. The heater should be
positioned observing the minimum clearances stated around the heater - see Fig. 1 and Fig. 2.
DO NOT locate the heater immediately below a fi xed socket outlet or connection box.
1. Remove wall mounting bracket from the back of the heater by depressing the spring latch
at the top of each bracket - see Fig. 3.
2. Fix the wall bracket securely to the wall through the four screw holes provided.
3. Present the heater to the wall bracket, and engage lower slots in the back with bracket.
4. Raise the heater to upright position and push the heater onto bracket to engage top latches.
General
Wall Mounting
Model(s) Watt (kW) A (mm)
QRAD050E 0.50 kW 513
QRAD075E 0.75 kW 513
QRAD100E 1.0 kW 675
QRAD150E 1.5 kW 756
QRAD200E 2.0 kW 918
