8
105 mm
Shelf
300 mm
300 mm
Minimum front clearance
Fig. 1
150 mm (Min)
150 mm (Min)
546 mm
A
Model (s) B (mm)
QRAD050E 225
QRAD075E 225
QRAD100E 387
QRAD150E 468
QRAD200E 630
260 mm
(Min)
B
275 mm
294 mm
(Min)
150 mm (Min)
Fig. 2
Fig. 3
