Dimplex QM100RF Operating Manual

- 15 -
To choose a timer mode, press Menu from the home screen. Rotate the Dial to highlight ‘Modes’, then press Dial to
select. ‘Timer Mode’ should be highlighted, press the Dial to select.
Available Timer Modes
A list of Timer Modes will be shown. Their default settings are shown in the table below.
For User Timer, Home All Day and Out All Day, three choices will be available:
Select - This option will activate the timer
Modify - This option allows the timer’s ‘Heating On’ times and Target Temperatures to be modified
Preview - This option displays the timer’s configuration. This is handy to quickly check the timer without being
able to change any values
Modes
Timer Mode
Frost Protect
Manual
21
°
C
ADVANCE
MENU
BACK
Main Menu
Boost
Mode
Settings
ADVANCE
MENU
BACK
ADVANCE
MENU
BACK
Period 1 Period 2 Period 3 Period 4
User Timer 06:30 – 09:30 21
°
C 11:00 – 13:00 21
°
C 15:00 – 17:00 21
°
C 18:00 – 22:00 21
°
C
Home All Day 08:00 – 21:00 21
°
C 00:00 – 00:00 00:00 – 00:00 00:00 – 00:00
Out All Day 07:00 - 8:30 21
°
C 17:30 - 22:00 21
°
C 00:00 - 00:00 00:00 - 00:00
Away Mode
Away Mode does not operate in the same way as the other Timers.
See section ‘Away Mode’ on page 15
Timer Mode
User Timer
Home All Day
Out All Day
Away
Home All Day
Select
Modify
Preview
Highlight and select one of the available Timer Modes rotating and pressing the Dial.
ADVANCE
MENU
BACK
ADVANCE
MENU
BACK
