Seasonal settings
Summer
1
In summer when you hopefully don’t need
any heat you can switch the heater off at the
wall socket. Turn it on again when you need
heating.
Preparing for colder weather
2
Remember to turn the heater on at
the wall switch.
• Allow 24 hours for the heater
to ‘charge’.
• Adjust the controls as necessary.
• The INPUT control for XLS models should
not need to be seasonally adjusted.
Summer
OFF
X
6
Holidays – Winter
4
In the winter set the controls as shown to
protect the room from frost.
Holidays – Summer
3
In the summer the heater can be turned
off at the wall switch.
TIP Remember to first switch on at the socket.
When you switch the heater on again it may need
a ‘charge ‘before heat is available. There may be
a delay of 24-48 hours before heat is available.
OFF
X
OUTPUT
INPUT
TIP Remember there will be a delayed reaction
from the heater until the beginning of the charge
period when you switch on again.
TIP The INPUT control for XL (manual models)
should be set to max for Winter but a lower
setting should be sufficient during Spring and
Autumn. But if the heater is not providing the
correct level of heat it should be adjusted slightly
up or down as appropriate. Remember, any
changes will take 24 hours to take effect.
1
2
4
3
ON
3
Input
Output
(late boost)
Input
Output
(late boost)
TIP If the external temperature falls below – 3°C
it is likely that you will need supplementary heating
to maintain the normal temperature in the room.
1224-XLN/XLSN STORAGE HEATER INSTRUCTIONS.indd 7 14/01/2011 10:36
