Operation & Maintenance Manual Section2-Specification
Dingli Machinery
2-2
Turret Rotation
360°continuous
Platform Rotation
±90°
Jib Up/Down Angle
+70°/-60°
Tail Swing 0.73m 0.93m
Wheel Base 2.4m
Gross Machine Weight(Platform Empty) 9590kg 10100kg
Ground Clearance 0.279m
Tire and Wheels
Foam Filled Tire
Size 315/55 D20
Outer Diameter 830mm
Width 319mm
Airborne Noise Emission
Maximum Sound Level in the platform
＜70dB
Vibration Value
＜2.5m/s^2
2.2 Performance Specification
Driving Speed
Boom Stowed, high range 6.1km/h
Boom Raised or Extended 1.1km/h
Main Lift Up 35-40 sec
Main Lift Down 40-45 sec
Swing Right & Left 100-200 sec
Telescope Extent Out 30-35 sec
Telescope Retract In 30-35 sec
Platform Rotate R & L 5-10 sec
Jib Up 20-25 sec
Jib Down 20-25 sec
