DINGLI JCPT2212DC - Maintenance; Maintenance Overview and Schedule

OPERATOR’S MANUAL with Maintenance Information
Operating Instructions
35
Closed latch
Open latch
Platform extended
Platform not extended
Emergency operating with hand
pump
Emergency Lowering
1 Unplug the lever and put it into the hand
pump (1).
2 Press and hold the button (2).
3 Operate the hand pump with the lever, the
platform should lower.
Retracting outriggers
1 Unplug the lever and put it into the hand
pump (1)
2 Press and hold the button (4).
3 Choose the outrigger which needs to
retract, Press the corresponding knob in
the direction of the arrow.
