DINGLI JCPT2223RT - Legend

OPERATOR’S MANUAL with Maintenance Information
Legend
8
Legend
1 Platform entry gate
10 Lift Cylinder
2 Main Platform
11 Engine(behind cover)
3 Lanyard anchorage point
12 Outrigger
4 Platform guard rails
13 Front wheel
5 Platform extensions
14 Hydraulic tanks、Fuel tanks (behind cover)
6 Manual storage containers
15 Ground controls
7 Platform controls
16 Rear wheel
8 Scissor Arms
17.Entry ladder
9. Safety arm
15
6
1
3
4
2
5
7
8
9
10
11
12
14
17
13
16
