DINGLI JCPT2223RT - Decals

OPERATOR’S MANUAL with Maintenance Information
Decals
9
Decal Inspection
Use the pictures on the next page to verify that all decals are legible and in place.
Below is a numerical list with quantities and descriptions.
No.
Part No.
Description
Qty.
Remark
1
37424
Decal, Symbols-Refer the operator to the
instructions for use
2
2
37435
Decal, Symbols-Tip-over hazard, outrigger
1
3
44343
Decal, Instructions-Directional arrows
1
4
37416
Decal, Symbols-Tip-over hazard, tilt-alarm
1
5
37440
Decal, Symbols-General safety rules
1
6
37422
Decal, Label-Lanyard anchorage point
8
7
48064
Decal, Label-Capacity 750kg
1
8
48044
Decal, Symbols-Crushing hazard
7
9
38437
Decal, Symbols-Do not alter or disable limit switch
1
10
48061
Decal, Instructions-Maximum wheel load: 4030kg
4
11
36550.A
Decal, Symbols-Collision hazard
4
12
34926
Decal, Instructions-Tie down point
4
13
34928
Decal, Instructions-Lift point
4
14
48060
Decal, Instructions-Maximum outrigger load: 4030kg
4
15
48037
Decal, Symbols-Crushing hazard
4
16
34240.A
Decal, Symbols-Main power switch operation
1
17
34929
Decal, Label-CE
2
18
37429
Decal, Symbols-Explosion/burn hazard
1
19
37432
Decal, Symbols-Electrocution hazard
2
20
48045
Decal, Symbols-Burn hazard (under the cover)
1
21
37430
Decal, Symbols-Safety arm
2
22
48043
Decal, Symbols-Max. manual force 400N
2
