DINGLI JCPT2223RT - Specifications

OPERATOR’S MANUAL with Maintenance Information
Specifications
13
Model DS2223RTA
Height, working maximum
22m
Height, platform maximum
20m
Height, drive maximum
12 m
Height, stowed maximum
Rails up
3.75m
Height, stowed maximum
Rails folded
2.91m
Width
2.33m
Length, platform retracted
4.9m
Platform dimensions
Platform length x width
4.35m×1.85m
Platform extension length
2.0m
Maximum load capacity
750kg
Maximum wind speed
12.5m/s
Wheelbase
3.13m
Turning radius (outside)
4.6m
Turning radius (inside)
2.1m
Ground clearance
36cm
Weight
See Serial Label
Machine weights vary with option configurations
Controls
Proportional
AC outlet in platform
Standard
Maximum hydraulic pressure
(functions)
240bar
Tire size
355/55D625
Airborne noise emissions
<80 dB
Maximum sound level at normal operating
workstations (A-weighted)
Vibration value does not exceed 2.5m / s
2
Maximum slope rating ,
Stowed position
30%
Maximum side slope rating
Stowed position
25%
Note: Slope rating is subject to ground
conditions and adequate traction.
Maximum working slope
X-2°, Y-3°
Drive speeds
Stowed, maximum
6.0 km/h
Platform raised, maximum
0.5 km/h
Floor loading information
Tire load, maximum
4030kg
Outrigger load, maximum
4030kg
Tire contact pressure
740kPa
Occupied floor pressure
11.8kPa
Note: Floor loading information is approximate
and does not incorporate different option
configurations. It should be used only with
adequate safety factors.
Continuous improvement of our products is a
DINGLI policy. Product specifications are
subject to change without notice or obligation.
