OPERATOR’S MANUAL with Maintenance Information
Legend
8
Legend
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
1 Platform guard rails 10 Non-steer tire
2 Platform controls 11 Entry ladder
3 Manual storage container
(on opposite side of machine)
12 Battery charger
(on the entry ladder end of machine)
4 Platform extension 13 Safety arm
5 Scissor Arms 14 Platform extension release pedal
6 Lift Cylinder 15 Main Platform
7 Steer tire 16 Lanyard anchorage point
8 Ground controls 17 Platform entry gate
9 Pothole guard
