DINGLI S06-EH User Manual

OPERATOR’S MANUAL with Maintenance Information
Control Panel
14
Ground Control Panel
For S06-EH
1 Key switch
Turn the key switch to the platform position
and the platform controls will operate. Turn
the key switch to the off position and the
machine will be off. Turn the key switch to
the base position and the ground controls
will operate.
2 Platform up / down switch
Move the switch up and the platform will
raise. Move the switch down and the
platform will lower.
3 Circuit breaker
When the current was overloaded, the
circuit breaker will cut off the circuit.
4 Overload indicator light
Light on indicates when overloaded.
5 Red Emergency Stop button
Push in the red Emergency Stop button to
the off position to stop all functions. Turn
the red Emergency Stop button clockwise
to the on position to operate the machine.
1 2 3 4 5
