OPERATOR’S MANUAL with Maintenance Information
Maintenance
46
A-4
Check the Hydraulic Oil Level
Maintaining the hydraulic oil at the proper level
is essential to machine operation. Improper
hydraulic oil levels can damage hy draulic
components. Daily checks allow the inspector
to identify changes in oil level that might
indicate the presence of hydraulic system
problems.
Perform this procedure with
the platform in the stowed position.
1 Visually inspect the sight of hydraulic oil
level from the side of the hydraulic oil tank.
⊙ Result: The hydraulic oil level should be at
the mark of the fuel tank. (Refer to the
following table).
Model Scale line（L）
S06-EH/S06-E 7.2
2 Add oil if necessary. Do not overfill.
Original Hydraulic oil
specifications：L-HV46
Customers shall choose the appropriate
hydraulic oil according to the ambient
temperature used.
Example: L-HV32 or L-HV68
A-5
Perform Function Tests
Completing the function tests is essential to
safe machine operation. Function tests are
designed to discover any malfunctions before
the machine is put into service. A
malfunctioning machine must never be used. If
malfunctions are discovered, the machine
must be tagged and removed fro m service.
Complete information to perform this
procedure is available in the appropriate
operator’s manual. Refer to the operator’s
manual on your machine.
