OPERATOR’S MANUAL with Maintenance Information
Schematic
82
S1012EH S1212EH
Lower valve
NBCY-1001A-11
Lower valve
NBCY-1001B-11
120bar
235bar
3.45bar
RV2=150bar
（
S1012EH
）
RV2=190bar
（
S1212EH
）
180bar
Pump
5802-4-12
Valve 5805-0116R
Tank
Platform loading
(
Option
)
Steer cylinder
Lift cylinder
Upper lift cylinder
Hand pump
5805-0412(960020A10)
SV2
1mm
1mm
S1
S2
P
M
T
BRK
RV1
SV1
FR
RV4
CV2
RV3
CV1 1.1mm
SV4
RV5
CV2
0.9mm
1.5mm
SV3
D3
D2
D1
D4
L
P41
P42
