Dingtek DF702 User Manual

Beijing Dingtek Technology Corp., Ltd. Tel:86-10-64718863, 64753700
http://www.dingtek.com E-mail: service@dingtek.com
Room A209, Flounder Business Park, Shunbai Road 12, Chaoyang District, Beijing, China 100022 Page
7
Figure4.1
 4.2 Reverse side of picture of PCB board ( open the Screws of PCB Board) as shown in
figure 4.2.
TX
RX
GND
Hollow position
Solid position
Black part of the jumper cap,
the default in this position
This interface can be used to
modify Lora parameters as well
as debug module
This power socket is
used to connect the
Battery
+
-
