Dini Argeo DGT4X User Manual

7
12
11
10
9
888888
888888
888888
i
div.deC
div.deC
...
0.Calib
div.deC
div.deC
...
zero
Span
div.deC
...
adC.v
QSG_ENG_DGT4X
Complete menu
at page 4
8. Zeroing of the mechanic tare (pre-tare zeroing)
Zeroing of the pre-tare (or mechanical tare).
This functionality allows to zero the weigh of the scale structure (e.g. empty silo, conveyor, etc.) without changing the calibration in
memory.
9. Calibration with sample weight
Zero point acquisition.
1. Unload the scale.
2. Enter the
zero
step to adjust the
zero point.
5. Save adjustment (Press key
many times until
save?
message will
appear, then press to confirm).
Sample weight acquisition.
3. Load the scale with span weight.
4. Enter the
span
step, type the span
weight value and press to adjust.
10. Diagnostic of the load cell V/V
It allows to verify signal of each channel. It must be included into the range 0 to 3 mV/V.
Signal have to be stable and it have to increase by increasing the weight on the scale.
With more channels connected, it’s possible to scroll between channels with keys and .

Dini Argeo DGT4X Specifications

General

Brand	Dini Argeo
Model	DGT4X
Category	Transmitter
Language	English
