Dini Argeo DGT4X User Manual

9
15 1
2
888888
div.deC
...
485 div.deCse.add
bad
i
16 1
2
3
4
5
888888
div.deC
...
exCl.Ch div.deCnone
Ch 1
Ch 2
Ch 3
Ch 4
QSG_ENG_DGT4X
Complete menu
at page 4
13. RS485 port
485 address (01 ÷ 98).
Baud rate (1200, 2400, 4800, 9600, 19200, 38400, 57600, 115200).
The RS485 port is configured by default to communicate in Modbus RTU (ch. 18).
14. Broken laod cell exclusion (for dependent channels systems)
No channel excluded.
Channel 1 excluded.
Channel 2 excluded.
Channel 3 excluded.
Channel 4 excluded.
If a load cell is broken, it’s possible to temporarely exclude the channel where it is connected and continue to weigh, pending
replacement.
WARNING: this operation reduces the accuracy of the weighing system. We recommend use for liquid weighing or in applications
where the load is evenly distributed.
Visible only in DEP.Ch mode.
