3590EKR, 3590EXP, 3590EXT, 3590 EBOX, CPWE, CPWET series indicator E-AF03_05.01_14.07_EN_T.doc
<< bAnd3 >> BANDS 3 WEIGHT/PRICE: threshold for setting a price for the third weight range.
<< bAnd4 >> BANDS 4 WEIGHT/PRICE: threshold for setting a price for the fourth weight range.
<< bAnd5 >> BANDS 5 WEIGHT/PRICE: threshold for setting a price for the fifth weight range.
<< bAnd6 >> BANDS 6 WEIGHT/PRICE: threshold for setting a price for the sixth weight range.
FOR EXAMPLE: if one wants to set 3 thresholds: 1) 0.50 € for a weigh greater than 100 kg; 2) 1.00€ for a weigh greater
than 5000 kg 3) 2.00 € for the weigh greater than 10000 kg.
WEIGHT/PRICE THRESHOLD 1 >> 100 kg >> 0.50 €
WEIGHT/PRICE THRESHOLD 2 >> 5000 kg >> 1.00 €
WEIGHT/PRICE THRESHOLD 3 >> 10000 kg >> 2.00 €
<<hiSt>> HISTORICS: historical report of the entered total amount. By pressing Fn one is asked to clear.
The coin box has its own configuration programme and a relative technical manual.
7.4 RFID READER
Connecting the RFID READER to the PC
Connect the RFID to the serial of the PC with the appropriate cable the RFID READER model “ID CPR40.00 A”,
connecting the AMP with with the power cables on the COM AUX of the indicator
RFID Configuration with Software PC
To configure the RFID READER you must have installed the program “ID ISOStart” from the CD
Once connected the RFID READER to the PC, run the Program indicated above (ID ISOStart..) and will see a screen
like this:
