DINKING DK4000i - Technical Parameters

24
TECHNICAL PARAMETERS
Engine
Engine Model
164F/P
Engine Type Single Cylinder, Four Stroke, Air Cooled, Overhead Valve
Cylinder Diameter×Stroke
(mm)
64x45
Displacement(cc) 145
Compression Ratio 8.5±0.2
Gas Distribution Mode OHV
Cooling Mode Forced Cold Air
Output Power(kW/r/min) 4.0/4850
Starting Mode Manual Recoil Starting
Fuel Tank Capacity(US
gallon)
1.0 (3.7L)
Type And Grade Of Fuel Unleaded Gasoline For Vehicles
Lubricating Oil
Capacity(US gallon)
0.12 (0.45L)
Lubricating Oil Model
SAE 10W/30
Lubrication Way Splash Lubrication
Generator
Noise dB(7m@50% load) 62
Rated Power(kW) 3.2
Max Power(kW) 4.0
Rated Voltage(V) 120
Rated Frequency(Hz) 60
Power Factor 1
Number of Phase Single phase
DC Output
12V/8.3A
Configure
Electric Machinery Permanent Magnet
Voltage Regulation Controller Regulation
Frequency regulation Controller Regulation
Dimensions(in)
18.9'×11.4'×17.3' (480×290×440mm)
Net Weight(lb) 45.2 (20.5kg)
