Dino-Power DP-X3 User Manual

28
Troubleshooting
Problem
Cause
Solution
Pump is primed, but can not
achieve good spray pattern.
Spray tip may be partially clogged.
Clear spray tip clog.
Reversible spray tip is in UNCLOG
position.
Rotate arrow-shaped handle on spray
tip so it points forward to SPRAY
position.
Debris in paint.
Strain the paint.
Pressure is set too low.
Alignpressure control knob
setting indicatortodesired spray
setting.
Spray gun fluid filter is clogged.
Clean or replace gun fluid filter.
Spray tip selected is too large
for capability of sprayer.
Replace tip.
Spray tip is worn beyond
the capability of sprayer.
Replace tip.
Spray tip gasket and seal worn
or missing.
Replace gasket and seal.
Inlet strainer is clogged or
suction tube is not immersed in
paint.
Clean debris off inlet strainer and
make sure suction tube is
immersed inpaint.
Extension cord is too long or
not heavy enough gauge.
Replace extension cord.
Inlet pump valve or outlet pump
valve is worn or clogged with debris.
Check for worn or contaminated
inlet valve or outlet valve.
- Prime sprayer with paint
- Trigger gun momentarily
- When trigger is released,
pump should cycle momentarily
and stop
- If pump continues to cycle, pump
valvesmaybewornor
contaminated with debris
- Cleanandreinstallvalves
Material is too thick.
Thin material. Follow manufacturers
recommendations.
Airless hose is too long (if
extra section was added).
Remove section of airless hose.
Spray gun stopped spraying
while trigger is pulled.
Spray tip is clogged.
Clear spray tip clog.
Sprayer lost prime.
See troubleshooting section “Sprayer
runs, but pump does not prime or
looses prime while in use.”
