System Testing and Impact Sensor Adjusting

RF Security Setting

Arming

1. Press the

A U X

button on the remote

2. Doors lock, Lights ﬂash and the horn/siren sounds once

• For silent arming; press the AUX button prior to pressing the

A U X

button.

3. Dome light turns off, starter kill becomes active, and the status LED begins ﬂashing.

4. While arming, the system tests the trigger inputs for status. If any trigger inputs are active when arming

the horn/siren sounds a second time as a notiﬁcation, both the onboard impact sensor and the active

input are bypassed. The open zone is bypassed until corrected and the impact sensor is bypassed for

a maximum of 4 minutes. While bypassed, the active input is indicated by the status LED ﬂashes (see

table of zones for LED ﬂashes).

5. Sensor testing:

a. Gently impact the vehicle with increasing intensity to test the pre-trigger level (10 horn/siren sounds.

b. Impact that location more heavily to test the full-trigger level (horn/siren/lights for 30 sec.)

c. Adjust the sensor pot until the desired levels are obtained

Note: The Nuisance Prevention feature bypasses the sensor after three full-triggers; to reset if active,

disarm the system and turn the ignition on/off.

6. Protected entry tests:

• Open each door, the horn/siren sounds quickly and then begin the full-trigger output

• Open the hood or trunk, or turn on the ignition to immediately begin the full-trigger output.

Note: The Nuisance Prevention feature bypasses an input that stays active for three full-triggers; close the

input to reset.

Sensor Bypass

1. Press and release the AUX button within 5 seconds after

A U X

button, the lights ﬂash two times and the

pre-trigger output is bypassed

2. Press and release the AUX button again within 5 seconds, the lights ﬂash three times and the pre-trig-

ger and full-trigger outputs are bypassed

3. Press the

A U X

button anytime to reset the sensor

Disarming

1. Press the

A U X

button

2. Doors unlock, Lights ﬂash and the horn/siren sounds two times. If the system has been triggered, the

horn/siren sounds four times or ﬁve times if the sensor is bypassed

• For silent disarming; press the AUX button prior to pressing the

A U X

button.

3. Dome light turns on, starter kill becomes inactive, and the status LED turns off.

• If triggered, the status LED continues to ﬂash to indicate triggered inputs (see table of zones). Turn

on the ignition to reset the LED.

4. Press the

A U X

button again to unlock the passenger doors if 2nd unlock is connected

Trunk Release

1. Press and hold the AUX button

2. Factory alarm will disarm if the output is connected

3. Trunk opens

Note: If the system is armed, the trunk input and sensor is bypassed until the trunk is closed. Trunk shunt

bypass requires the Blue trunk trigger input to be connected to the vehicle to bypass when armed (see Blue

wire description for wiring information).

Panic

1. Press and hold the

AUX

button

2. The lights ﬂash and the horn/siren sounds for 30 seconds.

3. Press the

AUX

A U X

buttons to reset

Car Finder

1. Press and release the AUX button prior to pressing the

AUX

button

2. The horn/siren emits one sound and the lights ﬂash 10 times

3. Press the

A U X

buttons to stop the feature.
