9
© 2012 Directed. All rights reserved.
Remote start shutdown diagnostics
If the remote start activates but fails to stay running, the remote start module has the ability to inform you of
what may have caused the remote start failure. Before performing shutdown diagnostics it is important that
you let the remote start shut off on its own i.e. let it attempt to start 3 times then shut down, if this is not done
the unit will report the shutdown you used to shut off the remote start.
Note: Shutdown diagnostics does not report if the vehicles factory immobilizer is causing the problem.
To perform shutdown diagnostics:
1. With the ignition Off, press and hold the Valet button
2. Turn the ignition On and then back Off while holding the Valet button.
3. Release the Valet button.
4. Press and release the Valet button. The status LED flashes to report the last shutdown for one minute or
until the ignition is turned on, as shown in the following table:
Status LED Flashes Shutdown Mode
1 flash Runtime expired
2 flashes Over-rev shutdown
3 flashes Low or no RPM
4 flashes Transmitter shutdown (or optional push button)
5 flashes (-) Hood shutdown (H3/4 GRAY)
6 flashes (+) Shutdown (H3/3 BROWN)
7 flashes Neutral safety shutdown (H3/1BLACK/WHITE)
8 flashes Wait-to-start timed out
Remote programming
1. Turn key to the ON position
2. Within 5 seconds, press and release Valet button one time.
3. Within 5 seconds, press and hold the Valet button. The LED will flash one time and the horn honks to
confirm entry into remote programming.
4. Press the
button ( or the single button ) on the remote control.
5. The horn honks to confirm the remote has been programmed.
6. Release the Valet button, and turn the key to the Off position.
7. The horn sounds one long honk to confirm that remote programming has been exited.
The programming routine exits if any of the following occurs:
• The ignition is turned off
• There is no activity for 30 seconds
• The Valet button is pressed too many times
