onds later.
disarming diagnostics
Extra disarm horn honks are the tamper alert. If four short horn honks
are heard when disarming, the system was triggered in your absence.
If five short horn honks are heard, a zone was triggered so many times
that false alarm prevention circuitry has bypassed that zone. In either
case, the status LED will indicate which zone was involved (see Table of
Zones section). The system will retain this information in its memory,
and the horn honks four or five times each time it is disarmed, until the
next time the ignition key is turned on.
table of zones
The zone number is the number of LED flashes used by the system to
identify that input. The standard input assignments are listed below.
ZZOONNEE
(Number
LED Flashes)
DDEESSCCRRIIPPTTIIOONN
11
Instant trigger - often used
for hood/trunk pin switches
22
Instant trigger - a heavier impact
detected by the shock sensor
33
Door switch trigger
44
Optional sensor
55
Ignition trigger
The LED will not report if the Warn Away response is triggered.
