Appendix A - Installation
64
When working with
cables, be sure to
connect corresponding
outputs and inputs
(Video OUT to Video IN,
Right Audio OUT to Right
Audio IN, etc.). Never
connect an IN to an IN or
an OUT to an OUT.
All A/V jacks and inputs
are color coded. Always
match the color of the
plug to the same color of
the jack.
OUT IN
S-Video & Digital Optical (or A/V Audio) Connection (Best Quality)
Using the S-Video cable, connect one end to the S-VIDEO output jack on the DIRECTV Plus DVR and
the other end to the S-Video input jack on the TV.
If your TV has a Digital Optical input, connect it to your DIRECTV Plus DVR using a digital optical
cable. (Note: is cable is not included with your DIRECTV Plus DVR.)
Otherwise, using the A/V cable, connect the white and red plugs from one end of the A/V cable to the
AUDIO L (white) and R (red) jacks on the back of the DIRECTV Plus DVR. Connect the plugs from
other end of the A/V cable to the corresponding audio input jacks on your TV or VCR. Do not plug the
video (yellow) into either the DIRECTV Plus DVR or the TV.
If hooking up a VCR, use another A/V cable to connect the white and red plugs from one end of the
A/V cable to the audio L (white) and R (red) and video (yellow) Output jacks on the back of the VCR.
Connect the plugs from the other end of the A/V cable to the corresponding input jacks on your TV. en,
use another A/V cable to connect the white and red plugs from one end of the A/V cable to the AUDIO
L (white) and R (red) and VIDEO (yellow) OUTPUT jacks on the back of the DIRECTV Plus DVR.
Connect the plugs from other end of the A/V cable to the corresponding input jacks on your VCR.
Now, continue on page 72, “Connecting Your DIRECTV Plus DVR to Your Telephone Line.”
R16 UG Book.indb 64R16 UG Book.indb 64 10/29/07 2:51:50 PM10/29/07 2:51:50 PM
