Appendix A - Installation
66
A/V Connection (Better Quality)
Using the A/V cable, connect the white, red and yellow plugs from one end of the A/V cable to the AUDIO
L (white) and R (red) and VIDEO (yellow) output jacks on the back of the DIRECTV Plus DVR. Connect
the other end of the A/V cable to the corresponding A/V input jacks on your TV.
If hooking up a VCR, using another A/V cable, connect the white, red and yellow plugs from one end of
the A/V cable to the AUDIO L (white) and R (red) and VIDEO (yellow) output jacks on the back of the
DIRECTV Plus DVR. Connect the other end of the A/V cable to the corresponding input jacks on your
VCR.
en, run an A/V cable from the VCR’s A/V output to the TV’s A/V inputs. is will allow you to watch
videotapes. NOTE: If your TV only has one set of A/V input jacks, this connection can also be made by
running a RF cable from the VCR’s out to TV jack to the TV’s antenna in jack.
Now, continue on page 68, “Connecting Your DIRECTV Plus DVR to Your Telephone Line.”
To switch between
watching your VCR
and watching video
from your receiver, you
may need to program
the INPUT key on your
DIRECTV Remote. (See
page 72 for info.) Some
TVs also have a menu
button that allows
you to change the
video source using an
onscreen menu. If you
have trouble changing
the video source, refer
to the instructions that
came with your TV.
TIP
If your TV only has one audio input jack use AUDIO L (white) jack on the back of the DIRECTV Plus DVR to make the connection.
Important
R16 UG Book.indb 66R16 UG Book.indb 66 10/29/07 2:51:55 PM10/29/07 2:51:55 PM
