dirna Bergstrom Bycool Compact - Electric Wiring Diagram (Euro 6 Models)

COMPACT
Air conditioning for vehicles
13
EN
Na
ºC
ºF
TEMP
ON/OFF
-
+
+
F
D
C
P
T
-
+
+
F
D
C
P
T
EURO 6 - Electric wiring
Az Blue
N Black
R Red
V Green
B White
A Yellow
Na Orange
M Brown
Temperature
probe
Electronic
module
Blower
Cinta
Fan
Compressor
electronic
module
fusible 25A
en conector original
Fuse
Conectores
originales
25A
Compressor
electronic
module
Compressor
Compressor
10 A. Fuse
2,9 Amp.
PWM.
NTC 15KΩ a 25º
Comsuption 30 mAmp.
2,6 Amp.
IMPORTANT WARNING!
Take care not to invert polarities when connecting the unit to the power supply. If this were to
happen, the plate would not come on and the unit would not work.
