Dish Network DISH 500 - Multiple Orbital Location Dish Options

Installation Diagrams - Multiple Orbital Location Dish Options 3 - 2
Multiple Orbital Location Dish Options
LNBFs Switch Receivers/Tuners Supported Diagram
110º & 119º (2 Orbital Locations)
(if needed) (without additional switches)
DISH 500
DP Plus Twin n/a 2 dual (w/ DPP Separators) or 2 single-tuners 1
DP Twin (or 2 DP Duals/Singles) DP34 Switch 2 dual or 4 single-tuners n/a
DP Twin (or 2 DP Duals/Singles) DPP33 Switch 3 dual (w/ DPP Separators) or 3 single-tuners 2
DP Twin n/a 1 dual or 2 single-tuners n/a
DP Quad n/a 2 dual or 4 single-tuners n/a
2 DP Duals/Singles 2 DP21 Switches 1 dual or 2 single-tuners n/a
DISH 500H
2 DP Low-Noise Duals DP34 Switch 2 dual or 4 single-tuners n/a
2 DP Low-Noise Duals DPP33 Switch 3 dual (w/ DPP Separators) or 3 single-tuners n/a
110º, 119º, and Wing Dish (3 Orbital Locations)
DISH 500 with Wing Dish*
DP Plus Twin and DP Dual/Single n/a 2 dual (w/ DPP Separators) or 2 single-tuners 3
DP Twin and DP Dual/Single DP34 Switch 2 dual or 4 single-tuners n/a
DP Twin and DP Dual/Single DPP33 Switch 3 dual (w/ DPP Separators) or 3 single-tuners 4
DP Twin and DP Dual/Single 2 DP21 Switches 1 dual or 2 single-tuners n/a
110º, 119º, & 129º (3 Orbital Locations)
DISH 1000
DP Plus Twin and DP Dual/Single n/a 2 dual (w/ DPP Separators) or 2 single-tuners 5
DP Twin and DP Dual (or 3 DP Duals/Singles) DP34 Switch 2 dual or 4 single-tuners n/a
DP Twin and DP Dual (or 3 DP Duals/Singles) DPP33 Switch 3 dual (w/ DPP Separators) or 3 single-tuners 6
DISH 1000.2
DP Plus 1000.2 LNBF n/a 3 dual (w/ DPP Separators) or 3 single-tuners 7
3 DP Duals/Singles and 1000.2 Three-LNBF Bracket DP34 Switch 2 dual or 4 single-tuners n/a
3 DP Duals/Singles and 1000.2 Three-LNBF Bracket DPP33 Switch 3 dual (w/ DPP Separators) or 3 single-tuners 8
110º, 119º, 129º, with Wing Dish (4 Orbital Locations)
DISH 1000 with Wing Dish* DP Twin with 2 DP Duals (or 4 DP Duals/Singles) DPP44 Switch 4 dual (w/ DPP Separators) or 4 single-tuners 9
DISH 1000.2 with Wing Dish*
DP Plus 1000.2 LNBF and DP Dual/Single n/a 3 dual (w/ DPP Separators) or 3 single-tuners 10
3 DP Duals/Singles, 1000.2 Three-LNBF Bracket,
& DP Dual/Single
DPP44 Switch 4 dual (w/ DPP Separators) or 4 single-tuners 11
DP Plus 1000.2 LNBF and DP Dual/Single DPP44 Switch 4 dual (w/ DPP Separators) or 4 single-tuners n/a
* See Single Orbital Location Wing Dish Options. Wing dish must use a DP-compatible LNBF.
